CHY-TC504A Laboratory 550 degree High Temperature Hot Plate with 160*160mm plate size

CHY-TC504A high temperature hot plate is a precision temperature control hot plate max 550 degree heating temperature. It adopts anodized aluminum heating panel sprayed with white high-temperature ceramic paint. The TC504A have 160*160mm plate size can max working with 6" wafer.

Inquire Now Next Product

Products Description

Model No.	CHY-TC504A
Temperature range	RT~550℃
Panel size	160*160mm
Panel material	High ten perature stainless steel
Interactive mode	PID+LCD digital display (Supporting upper computer software control)
Number of editable temperature curves	40
Temperature control precision	±0.2℃
Temperature control stability	±0.2℃
Temperature control uniformity	≤±2%
Heating Power	1000W
Dimension of heating stage	190(W)190(D)150mm
Dimension of temperature controller	300(W)190(D)150mm
Net weight of heating stage	4.5kg
