Model No. | Pressure range | Piston Diameter | Pressure gauge | Pressure stability | Plate Diameter | Dimension |
PC-15 | 0~15T (0-30Mpa) | Φ80mm | Pointer pressure gauge | ≤1MPa/10min | Φ90mm | 245*175*390mm |
PC-24 | 0~24T (0-34Mpa) | Φ90mm | Φ105mm | 245*175*415mm | ||
PC-30 | 0~30T (0-31.5Mpa) | Φ110mm | Φ120mm | 275*195*420mm | ||
PC-40 | 0~40T (0-30Mpa) | Φ130mm | Φ140mm | 295*215*500mm |
