Model No. | Pressure range | Piston Diameter | Pressure gauge | Isostatic pressure | Vessel Size | Dimension |
PC-12J | 0~12T (0-17Mpa) | Φ95mm | Pointer pressure gauge | 0~300MPa 500MPa is availiable | Φ22*70mm | 305*195*530mm |
PC-20J | 0~20T (0-21Mpa) | Φ110mm | Φ30*150mm | 305*195*600mm | ||
PC-40J | 0~40T (0-30Mpa) | Φ130mm | Φ40*150mm | 355*215*710mm | ||
PC-60J | 0~60T (0-34Mpa) | Φ150mm | Φ50*150mm | 405*240*720mm |
