Power supply | AC 220V 50Hz;180W |
Main Axis speed | 0-3000rpm |
Rotating angle | 360° |
X axis sliding distance | 210mm; |
Z axis sliding distance | 110mm |
Positioning accuracy of stepper motor | 0.01mm |
Diamond saw size | Φ150±10mm |
Max Cutting depth | 50mm |
Size of loading block | 80mm×25.4mm |
Control method | PLC programmable control with touch panel |
Dimension | 580mm×560mm×660mm |
