Ultrasonic Spray Nozzle (20 KHz 3.5 KW) for High Viscosity Slurry Spray Pyrolysis

Ultrasonic Spray Nozzle (20 KHz 3.5 KW) for High Viscosity Slurry Spray Pyrolysis

Ultrasonic spray utilizes ultrasonic energy to break liquid and form the few-micron drop size. The ultrasonic spray nozzle can use low vibration energy to make liquid atomized via gravity and low-pressure compressed air. The 20 KHz and 3.5 KW ultrasonic spraying nozzle with a power generator the high viscosity solution spray pyrolysis coating or spray granulation due to the low frequency but high power.

Products Description

Model No.CHY-SP-HVS
Power supplyAC220/50Hz
Ultrasonic Output0 - 3.5 KW adjustable
Ultrasonic frequency20KHz
Ultrasonic Converter

PZT (piezoelectric zirconate titanate crystal)

Diameter: 25 mm

Spray Nozzle

Outer diameter: 20 mm

Inner diameter: 1 - 2 mm

Spraying speed:  0.1 - 0.3 ml/min

Compressed air flow rate: 1 - 500 sccm

Liquid solution viscosity range: 1 - 2,000 mPa·s (cPs)

Drop Size

Average: 10 um - 20 um

Dimension
400*225*285mm
